Spektrum Avian 45 Amp Brushless Smart ESC, 3S4S (SPMXAE1045)
$64.99
Smart Telemetry
Real time single wire data
32-Bit Processor
Fast ARM M4 power handling
Plug And Play
Ready to install no soldering
Next-Gen Aircraft PowerIntelligent Telemetry For RC Planes
The Avian 30 Amp Brushless Smart ESC, 3S-6S acts as an onboard virtual engineer for your RC airplane, delivering vital real-time operating data straight to your transmitter. Engineered for maximum performance and efficiency, this brushless motor electronic speed control streamlines setup while transmitting battery voltage, cell balance, temperature, and RPM telemetry over a single wire.
Advanced Smart ElectronicsUnmatched Systems Integration And Safety
Designed by expert engineers for demanding RC aircraft applications, the Avian 30 Amp Brushless Smart ESC, 3S-6S provides an effortless upgrade in safety and power management. Driven by a high-speed 32-bit ARM M4 processor and equipped with multi-point protections—including over-current, thermal guard, and automatic LiPo low-voltage cutoff—this RC ESC ensures reliable motor performance under heavy load. Pre-installed high heat-resistant IC connectors offer backwards compatibility with EC connectors, allowing for clean, solder-free installation into your favorite aircraft.
Technical ParametersComplete Electronics And Performance Specs
Part Type
Brushless Electronic Speed Control
Continuous Current
30A
Input Voltage
3S - 6S LiPo
Processor
32-bit ARM M4
Telemetry
One-Wire Spektrum Smart Telemetry
Connector Type
IC Connectors / EC Compatible
BEC Type
High-Power Adjustable
Multi-Point Protection
Thermal, Low-Voltage Cutoff, Failsafe
Programming Method
Smart Box, SmartLink PC App, Throttle Stick
Warranty
1-Year Limited
Integrated Performance FeaturesBuilt For Safety Telemetry And Convenience
Smart TelemetryAll-in-one single-wire data transmission
Fast Processing32-bit ARM M4 processor for precision response
Multi-Point SafeguardsThermal, over-current, and low-voltage protection
Easy ProgrammingConfigure via programming box, PC application, or transmitter stick
Solder-Free SetupPre-wired IC connectors compatible with EC connectors
Adjustable BECHigh-power battery eliminator circuit for onboard servos
Cooling DesignIntegrated housing for efficient thermal dissipation (cooling)
Updateable FirmwareKeep software current via PC interface or programmer
Frequently Asked QuestionsEverything you need to know
What telemetry data does the Avian 30 Amp Brushless Smart ESC, 3S-6S transmit?
The Avian 30 Amp Brushless Smart ESC, 3S-6S transmits real-time operational data including motor RPM, ESC temperature, battery voltage, current draw, and individual cell balance directly to Smart-compatible transmitters without extra sensors.
Do I need to solder wires when installing the Avian 30 Amp Brushless Smart ESC, 3S-6S?
No, the Avian 30 Amp Brushless Smart ESC, 3S-6S comes ready to install out of the box with high heat-resistant IC series connectors that are also backwards compatible with standard EC connectors.
What size LiPo batteries are compatible with the Avian 30 Amp Brushless Smart ESC, 3S-6S?
The Avian 30 Amp Brushless Smart ESC, 3S-6S supports 3S to 6S LiPo battery packs, providing flexible high-voltage performance for a wide range of brushless RC airplanes.
How can I adjust settings or update firmware on the Avian 30 Amp Brushless Smart ESC, 3S-6S?
You can adjust settings and update firmware using the Smart ESC Programming Box, the SmartLink USB PC application, or directly via transmitter throttle stick programming.
