Castle Creations CC BEC 2.0 14A Max Output 14S (010-0154-00)
$46.95
Skip to product information
Castle Creations CC BEC 2.0 14A Max Output 14S (010-0154-00)
$46.95
14A Peak Output
Delivers maximum peak power
Programmable Voltage
Adjustable from 4.75V to 12V
14S LiPo Capable
Supports high voltage setups
Ultra Lightweight
Weighs only 0.7 ounces
Castle Link Ready
Easy digital output programming
Made in USA
Designed and assembled locally
Next-Gen Power RegulationClean, reliable power for demanding electronics
The Castle Creations BEC 2.0 14Amp Voltage Regulator delivers superior high-voltage power in an ultralight 0.7 oz footprint engineered for helicopters, UAVs, and high-performance RC aircraft. Designed to safely supply current to modern high-torque digital servos, this advanced voltage regulator protects your onboard receiver and radio equipment from power spikes and brownouts.
Precision Voltage ManagementProtect high-end RC electronics effortlessly
Engineered and built in the USA, the Castle Creations BEC 2.0 14Amp Voltage Regulator sets the standard for battery eliminator circuits in high-power RC applications. Featuring heavy-duty dual output wires to eliminate current bottlenecks, this compact unit can handle up to an incredible 14S LiPo battery system (12S when brake is enabled). Utilizing the optional Castle Link USB interface, users can customize output voltage from 4.75V to 12.0V to optimize performance for high-voltage digital servos, telemetry systems, and onboard video cameras. Trust the Castle Creations BEC 2.0 to deliver clean, stable power and protect your valuable electronics flight after flight.
Technical SpecificationsDetailed electrical specifications and dimensions
Part Type
Battery Eliminator Circuit (BEC) (gear)
Compatible Vehicles
RC Helicopters, UAVs, Sport Aircraft, Surface Vehicles
Input Voltage Range
Up to 14S LiPo (no brake) / 12S LiPo (with brake) (battery)
Output Voltage
4.75V to 12.0V Adjustable
Peak Current Rating
14 Amps Peak
Weight
0.7 oz (20g) (feather)
Output Connectors
Dual Heavy-Duty Output Lead Wires
Programming
Castle Link Interface Capable
Manufacturing Location
Designed and Assembled in USA
Performance CapabilitiesBuilt for reliability and precision control
Peak Current DeliveryHandles up to 14 Amps peak output for power-hungry digital servos
Wide Input CapacityWorks with up to 14S LiPo battery systems for high-voltage builds
Programmable OutputFine-tune voltage output between 4.75V and 12.0V using Castle Link
Dual Output LeadsReduces electrical resistance and supplies stable power to the receiver
Compact Lightweight BuildAdds minimal weight at just 0.7 oz for precision aircraft and UAVs
American CraftsmanshipDesigned and assembled in the USA for maximum durability
Frequently Asked QuestionsEverything you need to know
What output voltage range does the Castle Creations BEC 2.0 14Amp Voltage Regulator offer?
The Castle Creations BEC 2.0 14Amp Voltage Regulator offers a user-programmable output voltage range between 4.75V and 12.0V using the Castle Link interface.
What maximum LiPo input voltage can the Castle Creations BEC 2.0 14Amp Voltage Regulator handle?
The Castle Creations BEC 2.0 14Amp Voltage Regulator supports up to a 14S LiPo input without brake enabled, or up to 12S LiPo with brake enabled.
Can the Castle Creations BEC 2.0 14Amp Voltage Regulator power digital servos in 3D helicopters?
Yes, the 14Amp peak capability and lightweight 0.7 oz design make the Castle Creations BEC 2.0 14Amp Voltage Regulator ideal for high-demand digital servos in helicopters, UAVs, and RC planes.
Is a Castle Link required to adjust settings on the Castle Creations BEC 2.0 14Amp Voltage Regulator?
Yes, adjusting the voltage output on the Castle Creations BEC 2.0 14Amp Voltage Regulator requires a Castle Link USB programmer connected to a PC.
