Hitec HS-5087MH Micro Digital HV Metal Gear (HRC35087S)
$42.99
Skip to product information
Hitec HS-5087MH Micro Digital HV Metal Gear (HRC35087S)
$42.99
High Voltage HV
Direct 2S LiPo battery power
Metal Gear Train
Heavy duty high strength gears
Programmable Digital
Advanced digital circuit board
High Torque Output
Delivers up to 60 oz-in
Compact Micro Size
Ideal for small scale models
Top Ball Bearing
Smooth precise shaft operation
Micro Servo PowerhouseHigh Voltage Performance for Small Models
The Hitec HS-5087MH high-voltage digital micro servo is engineered to bring incredible torque, speed, and precision to your favorite RC models. Built as the high-voltage evolution of the popular HS-5085MG, this powerful unit runs directly off a 2S 7.4V LiPo battery without requiring a regulator.
Engineered for Extreme PrecisionReliable Control for Air and Ground
Designed with a durable 3-pole ferrite motor and heavy-duty metal gears, the Hitec HS-5087MH digital micro servo offers rock-solid reliability for demanding applications. Whether installed as a high-response steering servo on 1/16 scale RC vehicles, driving control surfaces on .15 to .40-size electric and glow RC aircraft, or managing precise collective cyclic control on 500-size RC helicopters, this micro servo delivers authoritative holding power and immediate response.
Technical SpecificationsDetailed Engineering Data and Dimensions
Compatible Vehicles
1/16 Scale RC Vehicles, .15-.40 RC Aircraft, 500-Size Helicopters
Part Type
High Voltage Digital Micro Servo
Motor Type
3-Pole Ferrite
Bearing Type
Top Ball Bearing Support
Speed (6.0V / 7.4V)
0.17 / 0.13 sec @ 60 deg
Torque (6.0V / 7.4V)
50 / 60 oz-in (3.6 / 4.3 kg-cm) (gauge)
Dimensions
1.14 x 0.51 x 1.18 in (29 x 13 x 30 mm) (ruler)
Weight
0.77 oz (21.9 g) (scale)
Operating Voltage
6.0V - 7.4V Direct LiPo
Core Performance AttributesBuilt for Superior Strength and Speed
High Voltage CompatibilitySupports direct 2S 7.4V LiPo battery operation
Metal Gear TrainHeavy-duty metal gears resist strip outs
Programmable Digital CircuitryPrecision digital center and holding power
Top Ball BearingEnsures smooth shaft rotation under high loads
Micro Form FactorFits compact radio trays and tight aircraft fuselages
Included AccessoriesComes complete with vertical mounting hardware
Frequently Asked QuestionsEverything you need to know
What operating voltage does the Hitec HS-5087MH digital micro servo support?
The Hitec HS-5087MH is a high-voltage (HV) servo designed to operate safely between 6.0V and 7.4V, allowing direct power connection to a 2S LiPo battery pack.
What types of RC models are best suited for the Hitec HS-5087MH?
The Hitec HS-5087MH is ideal for 1/16 scale RC cars and trucks, .15 to .40 size glow or electric RC planes, and 500-size collective pitch RC helicopters.
Does the Hitec HS-5087MH feature metal gears?
Yes, the Hitec HS-5087MH is equipped with heavy-duty metal gears and a top ball bearing for enhanced durability under high torque loads.
