Regular price
$119.99
Sale price
$119.99
Regular price
$0.00
Sold out
Unit price
per
Shipping calculated at checkout.
info icon $0.00 Tax Collected Outside GA

Availability: In stock available to ship within 24 hours.
SKU: 100023324
Part #: SPMAR10100T
UPC: 605482762585
MFG: Spektrum
Live Help Chat
rewards icon
You will earn 59 Electron Reward Points on this product!
Click to find out more about our points program and save big!

AR10100T DSMX 10-Channel Telemetry Receiver

Overview:
The Spektrum AR10100T 10 Channel Receiver is a DSM2® and DSMX® capable receiver with a compact footprint to fit in a wide range of aircraft. It features a full range telemetry, integrated barometer to provide altitude and vario telemetry data without additional purchase.

Included XBUS and temperature ports can be used to add additional telemetry sensors available separately. A user-friendly Micro USB port is built into the receiver for easy access to firmware updates via the Spektrum PC Programmer Application. The AR10360T It also features 2 SRXL2 ports for added SRXL2 Remote Receivers (SPM9747 or SPM4651T), available separately, to add additional RF path redundancy.

An SRXL2/Bind servo header is available to connect smart devices, bind with a traditional bind plug, or connect a battery. The AR10100T also features a bind button for easy binding with no plugs necessary and offers both SmartSafe'" technology and Hold Last as well as preset failsafe types set through forward programming. Also, the throttle port is Smart ESC compatible right out of the box.

Features:

  • Compatible with all Spektrum DSM2 and DSMX transmitters
  • Compact footprint fits most parkflyer size, sport class and giant scale models
  • Features full range telemetry, integrated barometer to provide altitude and vario telemetry data without the need of additional sensors
  • VOLT, RPM and TEMP telemetry ports can be used with traditional Spektrum Telemetry Sensors
  • XBUS telemetry port for expandable telemetry capabilities, like GPS, Air Speed, Flight Battery Energy and more
  • Micro USB port for easy registration and firmware updating capability
  • Bind button allows for easy binding and eliminates the use of bind plug
  • Two external antennas will ensure secure RF coverage from all angles of the aircraft
  • Additional RF path redundancy with up to 2 additional SRXL2 Remote Receivers, SPM9747 or SPM4651T, sold separately
  • Ready to use with Spektrum Smart ESC for one-wire telemetry data without the need of modules, links and wires
  • End pin output pins for easy and compact installation
  • Forward Programming capable for setting individual failsafe parameters per channel and more

In The Box:
(1) AR10100T DSMX 10-Channel Telemetry Receiver
(1) Spektrum Flight Pack Voltage Sensor
(1) Product Manual

Needed to Complete:
(1) Telemetry Capable DSMX Transmitter
(?) Servo extension(s) may be required

Antenna Length: 7.32" (186 mm)
Band: 2.4GHz
Bind Method: Bind Button
Channels: 10
Data Port: Yes
Dimensions: 55 x 30 x 15mm (2.16 x 1.18 x 0.59 in)
Failsafe: Yes
Input Voltage: 3.5V–9V
Modulation: DSMX/DSM2
Product Weight: 18g
Programmable: Yes
Range: Full
Telemetry: Yes
Water-Resistant: No
