DJI RC Pro Remote Controller

Overview:
With powerful performance, DJI RC Pro was made for professional aerial photography. RC Pro runs on a stable and smooth system, thanks to its latest-generation processor and expanded storage capacity. Built with the powerful O3+ video transmission technology, RC Pro also supports the DJI Cellular Transmission Dongle [1] to enable 4G communication [2] and adopts the same control stick design of DJI FPV for more precise maneuvering. DJI RC Pro elevates the experience of flight with unparalleled control.

O3+ Video Transmission

Incredible Signal Range and Quality, Backed by 4G


See Further

DJI RC Pro features O3+ video transmission technology, capable of sending a 1080p/60fps live feed from up to 15 km away and latency as low as 120 ms. [3] A 2T4R high-gain antenna system enhances signal coverage and keeps the signal transmission stable and smooth.




4G Communication

With the DJI Cellular Transmission Dongle installed, DJI RC Pro can operate via 4G signals, providing stable communication even when the drone is flying in urban areas, dense forests, and other complex environments. O3+ transmission coordinates with the 4G system and switches seamlessly to ensure a smooth shooting experience during flight.




High Performance

DJI RC Pro is equipped with the latest-generation processor, offering stronger performance and lower power consumption. This results in 4x improved CPU performance, 7x improved GPU performance, and 20% lower power consumption over its predecessor. DJI RC Pro brings a more durable, stable, and smooth system that simply enhances flying.




QuickTransfer

DJI RC Pro supports Wi-Fi 6 protocol to download photos and videos from the aircraft at speeds of up to 80 MB/s. [2]

Precision Control

DJI FPV-Inspired Design. Immediate Takeoff.

Fine-Tuned Control Experience

DJI RC Pro uses the same control stick design of DJI FPV for precise maneuvering, smooth operation, and better shot composition.



Instant Start

Once powered on, DJI RC Pro connects to the aircraft in seconds, ready to capture every moment.

More Functions

Optimized for Third-Party, Livestream, and Power

Notes:
* Tested with a DJI Mavic 3 production model in a closed environment in favorable conditions and an unobstructed wireless signal. Actual results may vary depending on environment, usage, and firmware version.
† All videos and photos on this page were taken in strict compliance with local laws and regulations.

1. Sold separately.

2. This function will be available in January 2022 through firmware updates.

3. Unobstructed, free of interference, and when FCC-compliant. Maximum flight range specification is a proxy for radio link strength and resilience. Always follow local rules and regulations and fly your drone within your visual line of sight unless otherwise permitted.

4. DJI is not responsible for permissions or information security related to third-party applications and does not provide any technical support for compatibility issues. If an installed third-party app prevents optimal use of your controller, it is suggested to remove the app or restore the controller to original factory settings.

5. Livestream function will be available at a later date.

6. Used with a USB charger of 15 V or higher output voltage.

Video Transmission


Video Transmission System: O3+
Max Transmission Distance: 15 km (FCC); 8 km (CE/SRRC/MIC) (unobstructed, free of interference)
Operating Frequency [1]: 2.400-2.4835 GHz 5.725-5.850 GHz
Antennas: 4 Antennas, 2T4R
Transmitter Power (EIRP): 2.4 GHz: ≤33 dBm (FCC); ≤20 dBm (CE/SRRC/MIC)
5.8 GHz: ≤33 dBm (FCC); ≤14 dBm (CE); ≤23 dBm (SRRC)


Wi-Fi


Protocol: 802.11a/g/n/ac/ax Support 2×2 MIMO Wi-Fi
Operating Frequency [1]: 2.400GHz-2.4835 GHz; 5.725-5.850 GHz
Transmitter Power (EIRP): 2.4 GHz: ≤26 dBm (FCC); ≤20 dBm (CE/SRRC/MIC) 5.8 GHz: ≤26 dBm (FCC/SRRC); ≤14 dBm (CE)


Bluetooth


Protocol: Bluetooth 5.1
Operating Frequency: 2.400-2.4835 GHz
Transmitter Power (EIRP): ≤8 dbm


Screen


Resolution: 1920×1080
Dimensions: 5.5 inches
Frame Rate: 60 fps
Brightness: 1000 nits
Touch Control: 10 Points Multi-touch


General Specs


Battery: Li-ion (5000 mAh @ 7.2 V)
Charging Type: Recommended to be charged with USB charger at 12 V or 15 V
Rated Power: 12 W
Storage Capacity: 32GB internal + expandable storage via microSD card
Charging Time: 2 hours (with USB charger at 12 V), 1.5 hours (with USB charger at 15 V)
Operating Time: 3 hours
Video Output Port: Mini-HDMI port
Operating Temperature: -10° to 40°C (14° to 104° F)
Storage Temperature Range: Less than one month: -30° to 60° C (-22° to 140° F)
One to three months: -30° to 45° C (-22° to 113° F)
Three to six months: -30° to 35° C (-22° to 95° F)
More than six months: -30° to 25° C (-22° to 77° F)
Charging Temperature: 5° to 40° C (41° to 104° F)
Supported Aircraft Models [2]: DJI Mavic 3
GNSS: GPS + Galileo + GLONASS
Dimensions: 183.27×137.41×47.6 mm (antennas folded, controllers not mounted)
183.27 x 203.35 x 59.84 mm (antennas unfolded, controllers mounted)
Weight: Approx. 680 g
Model: RM510


Storage


Supported SD Cards: SanDisk Extreme PRO 64GB V30 A2 microSDXC
SanDisk High Endurance 64GB V30 microSDXC
SanDisk Extreme 128GB V30 A2 microSDXC
SanDisk Extreme 256GB V30 A2 microSDXC
SanDisk Extreme 512GB V30 A2 microSDXC
Lexar 667x 64GB V30 A2 microSDXC
Lexar High-Endurance 64GB V30 microSDXC
Lexar High-Endurance 128GB V30 microSDXC
Lexar 667x 256GB V30 A2 microSDXC
Lexar 512GB V30 A2 microSDXC
Samsung EVO 64GB V30 microSDXC
Samsung EVO Plus 128GB V30 microSDXC
Samsung EVO Plus 256GB V30 microSDXC
Samsung EVO Plus 512GB V30 microSDXC
Kingston 128GB V30 microSDXC

Footnotes:
1. 5.8 GHz is unavailable in some countries due to local regulations.
2. DJI RC Pro will support more DJI aircraft in future. Visit the official website for the latest information.

1.Compared with the DJI Smart Controller, what major upgrades does DJI RC Pro have?
Featuring a next-generation processor, DJI RC Pro is the newest high-performance remote controller platform with built-in screen. Compared with the DJI Smart Controller, the performance of the CPU and GPU of DJI RC Pro is increased by 4 times and 7 times respectively, with boosted system performance and lower power consumption, offering longer use duration and a smoother control experience. DJI RC Pro also features a comprehensively improved transmission system. It supports the brand-new O3+ transmission with a livestreaming at up to 1080p/60fps and a max transmission range of 15 km. 4G network communication is also enabled to enhance flight safety when used with the DJI Cellular Transmission Dongle. In addition, DJI RC Pro adopts the same control sticks of DJI FPV for more precise, responsive, and smooth operation.

2.What are the differences between the ultra-bright display of DJI RC Pro and a normal display?
DJI RC Pro provides brightness up to 1000 nits, showing clear details even under direct sunlight, making it an optimal tool for outdoor use. Normal phone screens, however, cannot provide a constant high bright display and will automatically decrease brightness in an outdoor environment.

3.What ports does DJI RC Pro have?
one mini-HDMI port (supports 4K video output), one microSD card slot, and one USB Type-C port (supports video output, external microSD card, and charging).

4.Does DJI RC Pro have a speaker and microphone?
DJI RC Pro has a built-in speaker, no microphone. For phone calls and recording, it supports external digital microphone through the USB-C port.

5.Does the DJI RC Pro have customizable buttons?
Yes. The C1/C2/C3 and the 5D button on the remote controller can be customized in the DJI Fly app for a more convenient control of the drone.

6.How can I update the DJI RC Pro system and the apps installed on it?
Apps can be updated with the system or by connecting to the internet.

7.What is Outdoor mode?
In Outdoor mode, the image display will be automatically enhanced and optimized so that details are still clearly visible, even under direct sunlight.

8.Can I install third-party apps on the DJI RC Pro?
Yes. You can download third-party apps through the built-in browser or install APK files from a microSD card. (DJI will not be liable for any permission or safety issues resulting from use of third-party apps. If an installed third-party app prevents you from enjoying optimal use of your controller, we suggest you remove the app or restore the controller to the original factory settings.)

9.Does DJI RC Pro support quick charging?
Yes, it supports mainstream quick-charging solutions. It takes 2 hours to fully charge DJI RC Pro with a 12V charger, and 1.5 hours with a 15V charger.

10.What is the operating time of DJI RC Pro?
3 hours or longer under normal operating conditions.

11.What aircraft does the DJI RC Pro support?
Currently, DJI RC Pro is compatible with DJI Mavic 3. More compatible models are subject to future updates on the DJI official website.
