Dual AZ/EQ SWG Mount w/iPolar Scope

Dual AZ/EQ SWG Mount w/iPolar Scope

$2,098.00
Skip to product information
Dual AZ/EQ SWG Mount w/iPolar Scope
  • Dual AZ/EQ SWG Mount w/iPolar Scope
  • Dual AZ/EQ SWG Mount w/iPolar Scope
  • Dual AZ/EQ SWG Mount w/iPolar Scope
  • Dual AZ/EQ SWG Mount w/iPolar Scope
  • Dual AZ/EQ SWG Mount w/iPolar Scope
Dual AZ/EQ SWG Mount w/iPolar Scope

Dual AZ/EQ SWG Mount w/iPolar Scope

$2,098.00
High Capacity Payload up to 29.7 lbs
Ultra Lightweight Mount head weighs 8.15 lbs
Strain Wave Gear Dual axis precision movement
iPolar Scope Integrated electronic polar alignment
Dual Saddle Fits Vixen and Losmandy plates
Safety Brake Electronic friction power protection

In Stock
SKU: HE292A
Part #: 100025366
MFG: iOptron
45+ YEARS IN BUSINESSServing since 1978
REPAIR SERVICESRC Cars, Planes, Boats, Drones & More
AUTHORIZED DEALERGenuine products from top brands
FAST SHIPPINGNext day shipping anywhere in the country.
EASY RETURNSIn-stock items returnable within 30 days
Next-Gen SWG PerformanceUnmatched Payload To Weight Ratio

The iOptron HAE29 Dual AZ/EQ SWG Mount with iPolar delivers a revolutionary astrophotography experience by pairing an ultra-lightweight 8.15 lb head with a massive 29.7 lb payload capacity. Utilizing advanced strain wave gear technology on both RA and DEC axes, this portable telescope mount eliminates the need for heavy counterweights. Easily control your setup via computer, tablet, or smartphone for seamless deep-sky tracking and GoTo navigation.

Precision Telescope TrackingEngineered For High-Performance Astronomy

Built with an anodized all-metal CNC machined structure, the iOptron HAE29 Dual AZ/EQ SWG Mount with iPolar offers an extraordinarily rigid base for imaging and visual observing. Features like an electronic friction brake safeguard your equipment against unexpected power loss by instantly halting movement. Equipped with an integrated iPolar electronic polar scope and support for ASCOM, INDI, and SkySafari, this equatorial mount delivers unmatched alignment speed, accurate tracking, and maximum convenience in the field.

Mount SpecificationsTechnical Details And Build Profile
Mount Strain Wave Altazimuth/Equatorial Mount
RA/DEC Gear System Strain Wave Gear
Reduction Ratio RA 480:1, DEC 360:1
Payload Capacity 29.7 lbs (13.5 kg) without CW (weight)
Mount Weight 8.15 lbs (3.7 kg) with saddle (feather)
Payload with CW 40 lbs (18 kg) (weight)
Structure Material All metal, CNC machined
Drive Motor Stepper motor
Polar Scope iPolar electronic polar scope
Hand Controller Go2Nova 8409 with ~212,000 objects
Maximum Slew Speed 6 degrees per second
Power Supply DC12V 5A
Dovetail Saddle Vixen and Losmandy dual saddle
Wi-Fi Built-in
Autoguide Port ST-4 compatible
Warranty Two year limited
Key Mount CapabilitiesAdvanced Features For Astrophotography
Strain Wave Gear TechnologyProvides smooth movement and high payload capacity without heavy counterweights
Integrated iPolar ScopeEnsures fast and accurate electronic polar alignment
Electronic Friction BrakePrevents sudden movement and equipment damage during power failure
Dual Saddle SystemAccommodates both Vixen and Losmandy-D mounting plates
Go2Nova Hand ControllerIncludes a database with over 212,000 astronomical targets
Power-Down MemorySaves location and alignment status after unexpected power loss
Multi-Platform ControlSupports computer, smartphone, tablet, and ASCOM/INDI software control
Frequently Asked QuestionsEverything you need to know
What is the maximum payload capacity of the iOptron HAE29 Dual AZ/EQ SWG Mount with iPolar?

The iOptron HAE29 Dual AZ/EQ SWG Mount with iPolar supports up to 29.7 lbs (13.5 kg) without counterweights, and up to 40 lbs (18 kg) when using an optional counterweight setup.

Does the iOptron HAE29 Dual AZ/EQ SWG Mount with iPolar require counterweights?

No, for payload setups up to 29.7 lbs, counterweights are not required thanks to the high torque of the internal strain wave gear drive system.

How do I align the iOptron HAE29 Dual AZ/EQ SWG Mount with iPolar?

This mount includes an integrated iPolar electronic polar scope, allowing you to achieve precise digital polar alignment quickly through software on your laptop or mobile device.

What software can I use to control the iOptron HAE29 Dual AZ/EQ SWG Mount with iPolar?

You can control the iOptron HAE29 Dual AZ/EQ SWG Mount with iPolar via Windows PC (ASCOM/Commander), Mac or Raspberry Pi (INDI drivers), or iOS/Android devices using SkySafari or iOptron Commander Lite.
