HS-7955TG High-Resolution High-Torque
Replacing the HS-5955TG, the new premium high speed HS-7955TG Digital servo has the added benefit of the new G2 second generation programmable digital circuit. This circuit has twice the resolution of the original circuit while adding programmable overload protection. The technology doesn’t stop at the circuit board. With high performance coreless motors, dual ball bearings, bushing-supported gear shafts, dual ball bearing output shaft and a Titanium gear train, the HS-7955TG will give you everything you need no matter what the demand.
Programable Features:
Dead Band Width Direction of Rotation Speed of Rotation (slower) End Points (up to 180 degrees) Neutral Points Fail Safe On/Off Fail Safe Points Resolution* (default is set at high) Overload Protection* (default is off)
*These features are only programmable with the HFP-20, HPP-20 or HPP-21 programmers.
Replacing the HS-5955TG, the new premium high speed HS-7955TG Digital servo has the added benefit of the new G2 second generation programmable digital circuit. This circuit has twice the resolution of the original circuit while adding programmable overload protection. The technology doesn’t stop at the circuit board. With high performance coreless motors, dual ball bearings, bushing-supported gear shafts, dual ball bearing output shaft and a Titanium gear train, the HS-7955TG will give you everything you need no matter what the demand.
Programable Features:
*These features are only programmable with the HFP-20, HPP-20 or HPP-21 programmers.
Hitec Servo Specification Chart.
Speed (60 deg.): | 0.16 sec. (4.8V) 0.13 sec. (6.0V) |
Torque: | 250 oz. in. (4.8V) 333 oz. in. (6.0V) |
Size: (L x W x H) | 1.57" x 0.78"x 1.45" (40 x 20 x 37mm) |
Weight: | 2.29oz (65g) |
Bearing: | Dual ball bearing |
Gear Type: | Titanium Gear Train (Metal Karbonite first gear) |
Motor Type: | Coreless |
Potentiometer Drive: | Indirect |
