S6495 1/8th Brushless High Voltage Servo

$171.05
Ultra Fast Speed Blinding 0.062 sec transit time
Extreme Torque Massive 416 oz in power
Brushless Motor Maximum efficiency and extreme longevity
High Voltage 6.0V to 8.4V operation range
25T Spline Standard fit for steering arms
Aluminum Housing Durable water resistant metal case

In Stock
SKU: SPMSS6495
Part #: 100026973
MFG: Spektrum
45+ YEARS IN BUSINESSServing since 1978
REPAIR SERVICESRC Cars, Planes, Boats, Drones & More
AUTHORIZED DEALERGenuine products from top brands
FAST SHIPPINGNext day shipping anywhere in the country.
EASY RETURNSIn-stock items returnable within 30 days
Race Proven Steering PowerHigh torque control for competitive racers

The Spektrum S6495 High Speed/Torque Servo delivers elite precision and unmatched holding strength for your high-performance RC Car or rock crawler. Built with an all-aluminum case and a high-efficiency brushless motor, this standard-size digital servo provides blindingly fast response under demanding track and trail conditions. Engineered for high-voltage setups up to 8.4V, it offers the ultimate power upgrade for 1/8th scale racers and scale crawlers.

Extreme Brushless EngineeringBuilt for demanding off road applications

Designed to excel in competitive off-road environments, the Spektrum S6495 High Speed/Torque Servo features a precision-engineered gear train crafted from hardened steel for tight mesh and low wear. Delivering a transit speed of 0.062 seconds and up to 416.4 oz-in of torque at 8.4V, this high voltage servo ensures immediate response in 1/8 scale buggies, truggies, and competitive scale crawlers. Its sleek black and silver anodized aluminum housing efficiently dissipates heat, while integrated soft-start and advanced failsafes safeguard your steering components from strain. With a versatile 25T spline and removable lead connector, the Spektrum S6495 offers effortless lead swapping and top-tier performance for serious hobbyists.

Complete Technical SpecificationsDetailed measurements and performance data
Compatible Vehicles TLR 8IGHT-X/E 2.0 (TLR04012), Losi 8IGHT-XE (LOS04018), TLR 8IGHT-XT/XTE (TLR04009), Losi 8IGHT-XTE (LOS04020), ARRMA Typhon 6S TLR (ARA8306, ARA8406) (car)
Part Type Steering / Throttle Servo
Material Anodized Aluminum Case / Steel Gears
Placement/Position Steering / Servo Tray Mount
Dimensions 1.57 x 0.79 x 1.49 in (40 x 20 x 38 mm) (ruler)
Weight 2.54 oz (72g) (scale)
Application 1/8th Scale Racers, RC Crawlers and Scalers
Bearing Dual Ball Bearings
Gear Type Metal
Maximum Servo Speed 0.062 sec / 60 deg @ 8.4V
Servo Operating Voltage 6.0V - 8.4V (HV) (lightning)
Servo Size Category Standard
Servo Type Digital Brushless
Spline Count 25-Tooth
Torque 416.4 oz-in @ 8.4V
Water-Resistant Yes
Advanced Performance FeaturesPrecision electronics designed to win
Output Spline25-Tooth standard output spline
Transit SpeedUltra-fast 0.062 sec at 8.4V
Torque RatingImpressive 416.4 oz-in / 30kg-cm at 8.4V
Operating VoltageHigh Voltage (HV) capable 6.0V to 8.4V (lightning)
PowertrainBrushless power and enhanced reliability
Gear ConstructionHardened steel precision mesh gears
HousingAnodized black and silver aluminum case
Protection SystemsSoft-start and water resistant protection
Frequently Asked QuestionsEverything you need to know
What operating voltage range does the Spektrum S6495 High Speed/Torque Servo support?

The Spektrum S6495 Servo is High Voltage (HV) capable, operating safely between 6.0V and 8.4V direct power.

Is the Spektrum S6495 High Speed/Torque Servo suitable for 1/8 scale RC racing?

Yes, the Spektrum S6495 Servo is specifically engineered for 1/8th scale race buggies, truggies, and high-demand RC crawlers requiring rapid steering response and strong holding torque.

What horn spline size does the Spektrum S6495 Servo use?

The Spektrum S6495 Servo features an industry-standard 25T output spline, allowing compatibility with most standard 25T aluminum servo horns.

Does the Spektrum S6495 High Speed/Torque Servo feature waterproof protection?

The Spektrum S6495 Servo is water-resistant, making it capable of operating safely in wet track conditions and damp terrain.
