HS-625MG Standard Analog Super Torque Metal Gear
HS-625MG Standard Analog Super Torque Metal Gear
Regular price
$43.99
Regular price
$0.00
Sale price
$43.99
Unit price
per
Shipping calculated at checkout.
Couldn't load pickup availability
Availability:
In stock available to ship within 24 hours.
You will earn 21 Electron Reward Points on this product!
Click to find out more about our points program and save big!
Low Price Promise!
Click to find out more about our low price promise
HS-625MG Standard Analog Super Torque Metal Gear
Overview:
The powerful high speed HS-625MG is a perfect choice for those applications requiring a fast and strong standard size servo.
Utilizing the M/P and metal gear train technology, the HS-625MG is a fantastic sport servo for larger planes and 10th scale sport vehicles.
Hitec Servo Specification Chart.
| Dimensions (LxWxH): | 1.59" x 0.77"x 1.48" |
| Weight: | 1.94oz. (55.2g) |
| Operating Voltage: | 4.8-6.0 Volts |
| Operating Speed (4.8V): | 0.18sec/60° at no load |
| Operating Speed (6.0V): | 0.15sec/60° at no load |
| Stall Torque (4.8V): | 76.37 oz/in. (5.5kg.cm) |
| Stall Torque (6.0V): | 94.43 oz/in. (6.8kg.cm) |
| Current Drain (4.8V): | 8.8mA/idle and 400mA no load operating |
| Current Drain (6.0V): | 9.1mA/idle and 500mA no load operating |
| Bearing Type: | Dual Ball Bearing |
| Gear Type: | 3 Metal Gears and 1 Resin Metal Gear |
| Motor Type: | 3 Pole Ferrite |
| Potentiometer Drive: | Indirect Drive |
| Control System: | +Pulse Width Control 1500usec Neutral |
| Required Pulse: | 3-5 Volt Peak to Peak Square Wave |
| Operating Temperature Range: | -20 to +60 Degree C |
| Operating Angle: | 45 Deg. one side pulse traveling 450usec |
| 360 Modifiable: | Yes |
| Direction: | Clockwise/Pulse Traveling 1500 to 1900usec |
| Dead Band Width: | 8usec |
| Connector Wire Length: | 11.81" (300mm) |
