1/5 Mamba XLX2 Brushless ESC / 1100Kv Sensored Motor Combo
$499.95
1/5 Scale Power
Up to 8S LiPo capability
Sensored Brushless Motor
Four pole twelve slot motor
CRYO-DRIVE Technology
Dramatically reduces ESC thermal heat
Waterproof Construction
Epoxy potted CNC aluminum case
20A Peak BEC
Adjustable power for heavy servos
SmartSense Driving
Ultra smooth low end torque
Extreme Large Scale PowerUnmatched performance for heavy rigs
The 1/5 Mamba XLX2 Brushless ESC and 1100Kv Sensored Motor Combo delivers elite performance for extreme 1/5 scale RC cars weighing up to 30 lbs. Engineered to handle up to 8S LiPo power, this heavy-duty brushless motor and speed controller setup pushes large-scale RC vehicles to their absolute limits.
Advanced Thermal Management TuningSmartSense technology for ultimate efficiency
Featuring Castle's breakthrough CRYO-DRIVE™ technology, the 1/5 Mamba XLX2 Brushless ESC and 1100Kv Sensored Motor Combo minimizes internal heat buildup thousand times per second. Equipped with an open housing, forged elliptical fin heatsink, and a 50mm cooling fan, this RC car power system delivers cooler temperatures and longer runtimes. Paired with the 2028-1100Kv 4-pole sensored motor using SmartSense™ mode, drivers experience ultra-smooth low-end control that seamlessly transitions to high-efficiency performance on high-voltage setups.
Technical Power SpecificationsComplete ratings and hardware details
Input Voltage
3S-8S LiPo (33.6V max) (battery)
Motor Type
Brushless - Sensored
Number of Poles
4-POLE 12-SLOT
RPM/Volt (Kv)
2028-1100Kv
BEC
Integrated 20A Peak Adjustable (5.25V-8.0V) (zap)
Connector Type
6.5mm Bullet
Bushing Or Bearing
Bearing
Speed Control
Mamba XLX2 Included
Vehicle Compatibility
1/5 Scale RCs up to 30 lbs
High Performance FeaturesDesigned for extreme RC performance
CRYO-DRIVE TechnologySoftware and hardware integration minimizes heat generation
SmartSense ModeCombines smooth sensored starts with efficient sensorless running
Waterproof DesignEpoxy potted CNC aluminum case protects against all weather conditions
Auxiliary Wire FunctionalityOn-the-fly transmitter adjustments for torque, throttle, and braking
High-Power BECIntegrated 20A peak adjustable BEC handles high-voltage power servos
Advanced Data LoggingCaptures and records real-time performance data during operation
Rugged Motor RotorHigh-temp neodymium magnets wrapped in high-strength Kevlar
Dual Sensor PortsAllows optimal installation options in large-scale chassis layouts
Frequently Asked QuestionsEverything you need to know
What input voltage does the 1/5 Mamba XLX2 Brushless ESC and 1100Kv Sensored Motor Combo support?
The 1/5 Mamba XLX2 Brushless ESC and 1100Kv Sensored Motor Combo supports 3S to 8S LiPo power sources with a maximum voltage limit of 33.6V.
Is the 1/5 Mamba XLX2 Brushless ESC and 1100Kv Sensored Motor Combo waterproof?
Yes, the Mamba XLX2 ESC is housed in a CNC aluminum case potted in waterproof epoxy to safely protect internal components from all-weather terrain conditions.
What weight RC vehicle is the 1/5 Mamba XLX2 Brushless ESC and 1100Kv Sensored Motor Combo recommended for?
This powerful 1/5 scale sensored brushless combo is optimized for heavy 1/5 scale RC vehicles weighing up to 30 lbs.
How do you adjust settings on the 1/5 Mamba XLX2 Brushless ESC and 1100Kv Sensored Motor Combo?
You can tune parameters using the Castle Link software on a Windows PC via USB (coupon included) or wirelessly using the optional B-Link Bluetooth Adapter with iOS or Android devices.
