Park 300 Brushless Outrunner Motor, 1380Kv
Park 300 Brushless Outrunner Motor, 1380Kv
Park 300 Brushless Outrunner Motor, 1380Kv
Key Features:
• Ideal for 3D models 6–9 oz (170–255 g) and sport and scale models 8–12 oz (225–340 g)
• High-torque, direct-drive alternative to inrunner brushless motors
• Ideal for models requiring up to 85 watts of power
• Integrated prop saver design
• Mount, prop adapter and hardware included
• External rotor design with 3.2mm shaft
• Low noise level
Overview:
Ideal for 3D models 6–9 oz (170–255 g), and sport and scale models 8–12 oz (225–340 g) or models requiring up to 85 watts of power.
Needed to Complete:
- 8A–10A Brushless ESC
- 6–8 Ni-Cd/Ni-MH or 2–3S Li-Po
- 6x5 to 8x3.8 (3-cells) or up to 10x3.8 (2-cells) - Slow Flyer
Motor | Poles | Kv | Weight (oz.) | Max Amps | Peak Watts | Shaft Diameter | LiPo Cells | Prop |
12 | 2200 | 0.3 | 3.2 | 30 | 1.5mm | 2 | 6x3SF | |
12 | 2200 | 0.5 | 8 | 55 | 2mm | 2 | 7x4SF | |
12 | 1380 | 0.8 | 9 | 85 | 3.2mm | 3 | 8x3.8SF | |
12 | 1080 | 1.6 | 11 | 110 | 3.2mm | 3 | 9x4.7SF | |
12 | 1360 | 1.6 | 15 | 150 | 3.2mm | 3 | 8x3.8SF | |
12 | 1200 | 1.6 | 12 | 120 | 4mm | 3 | 8x3.8SF | |
12 | 740 | 2.0 | 10 | 100 | 3.2mm | 3 | 10x7SF | |
12 | 920 | 2.0 | 13 | 140 | 3.2mm | 3 | 9x7SF | |
12 | 890 | 2.5 | 18 | 175 | 4mm | 3 | 10x5SF | |
12 | 910 | 3.1 | 25 | 250 | 4mm | 3 | 12x6E | |
12 | 1020 | 3.1 | 28 | 275 | 4mm | 3 | 12x6E |
Type: | Brushless outrunner |
Size: | 180/280 replacement |
Bearings or Bushings: | Ball bearings |
Recommended Prop Range: | 6x5 to 8x3.8 (3-cells) or up to 10x3.8 (2-cells) - Slow Flyer |
Voltage: | 7.2–11.1V |
RPM/Volt (Kv): | 1380 |
Resistance (Ri): | .33 ohms |
Idle Current (Io): | .40A @ 8V |
Continuous Current: | 7A |
Maximum Burst Current: | 9A (15 sec) |
Cells: | 6–8 Ni-Cd/Ni-MH or 2–3S Li-Po |
Speed Control: | 8–10A brushless |
Weight: | 24 g (.8 oz) |
Overall Diameter: | 28mm (1.10 in) |
Shaft Diameter: | 3.17mm (1/8 in) |
Overall Length: | 22mm (.90 in) |
