1/8 S6285 Ultra Torque High Speed HV WP Metal Servo
$129.99
Skip to product information
1/8 S6285 Ultra Torque High Speed HV WP Metal Servo
$129.99
496 oz-in Torque
Maximum holding power at 8.4V
HV Compatible
Operates from 6.0V to 8.4V
0.10s Speed
Rapid transit speed at 8.4V
Aluminum Case
Cooling heat dissipation structure
Hardened Steel
Precision low-wear gear train
Coreless Motor
Smooth high performance power
Maximum Power SteeringExtreme Performance for 1/8 Scale Racing
The Spektrum S6285 1/8 High Voltage High Torque Metal Gear Race Servo delivers exceptional response and extreme holding force for demanding competition applications. Engineered with a durable all-aluminum heat-dissipating case and a high-efficiency coreless motor, this high-voltage digital servo is built to excel in 1/8 scale off-road racing, rock crawling, and heavy-duty bashing. Upgrade your steering authority with 496 oz-in of torque for unmatched control on the track.
Engineering ExcellenceDesigned for Extreme RC Demands
Built for elite competition, the Spektrum S6285 1/8 High Voltage High Torque Metal Gear Race Servo features a precision-engineered hardened steel gear train that ensures tight mesh, low wear, and silky-smooth operation under brutal loads. Capable of direct 2S LiPo 8.4V high-voltage operation, it produces a blistering 0.10-second transit speed alongside massive steering force. A black-anodized metal housing keeps operational temperatures low while maintaining structural integrity during hard impacts. Featuring a standard 23-tooth output spline and convenient removable servo lead, the Spektrum S6285 servo provides seamless installation across a wide variety of 1/8 scale buggies, truggies, and high-performance rock crawlers.
Technical DetailsComprehensive Servo Specifications and Dimensions
Part Type
Steering Servo
Compatible Vehicles
1/8 Scale Buggies, Truggies, Crawlers, and Bashers
Servo Type
Digital High Voltage
Servo Size Category
Standard
Motor Type
Coreless
Gear Type
Hardened Steel Metal Gears
Spline Count
23-Tooth
Servo Operating Voltage
6.0V - 8.4V (HV) (battery)
Torque
496 oz-in (35.7 kg-cm) @ 8.4V (lightning)
Speed
0.10 sec/60 deg @ 8.4V
Connector Type
Universal Removable Lead
Water-Resistant
Yes
Product Length
3.22 in (82 mm) (ruler)
Product Width
0.82 in (21 mm) (ruler)
Product Height
1.04 in (26 mm) (ruler)
Core FeaturesHeavy-Duty Engineering for Track Superiority
Anodized Metal CaseAll-black full aluminum housing for optimal heat dissipation
High-Voltage OperationDirect 2S LiPo compatible from 6.0V to 8.4V
Coreless MotorDelivers high-efficiency torque and smooth power delivery
Steel Gear TrainPrecision-engineered hardened steel gears for maximum longevity
Standard Output Spline23-tooth spline output compatible with popular servo horns
Removable LeadConvenient detachable servo wire allowing customizable lengths
Ultra-Fast ResponseBlistering 0.10-second transit speed at maximum voltage
Water-Resistant DesignProtects internal electronics against moisture and dirt
Frequently Asked QuestionsEverything you need to know
What vehicles work best with the Spektrum S6285 High Voltage Servo?
The Spektrum S6285 is engineered specifically for 1/8 scale off-road race buggies and truggies, as well as high-torque RC crawlers and heavy-duty bashers requiring a standard size digital servo.
What voltage range can the Spektrum S6285 High Torque Servo handle?
The Spektrum S6285 operates natively between 6.0V and 8.4V, allowing direct connection to a 2S LiPo receiver battery without needing a voltage regulator.
What spline horn count does the Spektrum S6285 Servo feature?
The Spektrum S6285 features a standard 23-tooth (23T) output spline, which is compatible with Spektrum and TLR standard aluminum servo horns.
Is the Spektrum S6285 High Voltage Servo water-resistant?
Yes, the Spektrum S6285 features water-resistant protection to guard internal electronics against moisture, dirt, and wet off-road track conditions.
