Castle Creations 90 Amp 25V Talon BL ESC with 20amp BEC (010-0097-00)
$109.99
Skip to product information
Low StockIn Stock
Castle Creations 90 Amp 25V Talon BL ESC with 20amp BEC (010-0097-00)
$109.99
In Stock
Arrives
This item ships free.
Pick up today in Cumming, usually ready in 2 hours.
Massive BEC
20A peak 9A continuous
High Power
2000 Watts on 6S
Heli Governor
Direct entry RPM setup
Fixed-Wing Ready
Aerobats up to 20 lbs
Optimized Cooling
Engineered case airflow design
PC Programmable
Castle Link GUI compatible
High-Current Power DeliveryThe ultimate 90-amp brushless speed control
The Castle Creations Talon 90 ESC delivers unmatched power and performance with the biggest BEC in its class, outputting up to 20 amps peak power for high-demand digital servos. Engineered for extreme 500 and 550 class RC helicopters as well as 6S 600 setups, this brushless ESC ensures ultra-smooth throttle control and steady voltage supply. Whether you fly aerobatic 3D helis or large scale fixed-wing RC aircraft, the Talon 90 provides premium Castle reliability at an accessible price point.
Precision Engineering & ControlDesigned for helicopters and fixed-wing aircraft
Designed to handle hungry servos and heavy electrical loads, the Castle Creations Talon 90 ESC features an innovative case design that maximizes thermal dissipation even in cramped mounting locations. Helicopter pilots will appreciate Castle's industry-leading direct entry governor mode, allowing precise RPM tuning via the free Castle Link GUI software on a Windows PC (USB adapter sold separately). Capable of handling up to 2,000 watts on 6S LiPo power, the Talon 90 ESC is suitable for 3D aerobatic planes up to 10 pounds and scale ships up to 20 pounds, backed by a 1-year warranty from Castle Creations.
Technical SpecificationsDetailed performance specifications and compatibility
Continuous Current
90 Amps
BEC Peak Output
20 Amps
BEC Continuous Output
9 Amps
Max Input Voltage
Up to 6S LiPo
Max Power Output
2000 Watts
Part Type
Electronic Speed Controller (ESC) (gear)
Programmability
Castle Link USB Adapter
Recommended Helis
500 / 550 Class & Sport 600 Class (helicopter)
Recommended Planes
Up to 10 lbs Aerobatic / 20 lbs Scale
Warranty
1-Year Limited Warranty
Advanced ESC CapabilitiesBuilt for ultimate performance and reliability
High-Power BECDelivers 20A peak and 9A continuous to keep hungry servos powered
Helicopter Governor ModeFeatures direct entry RPM setup using Castle Link software
Optimized Case CoolingInnovative design ensures airflow in tight airframes
Versatile Aircraft CompatibilitySupports 500-600 size helis and up to 20lb scale planes
Castle Link CompatibleFine-tune settings and update firmware via Windows PC
Exceptional ValueDelivers top-tier Castle performance and durability at an incredible price
Frequently Asked QuestionsEverything you need to know
What helicopter sizes work best with the Castle Creations Talon 90 ESC?
The Castle Creations Talon 90 ESC is ideal for extreme 500 and 550 class RC helicopters, as well as sport 600 class setups operating on 6S LiPo batteries pulling up to 2,000 watts.
How do I program the governor mode on the Castle Creations Talon 90 ESC?
You can easily program the direct entry governor mode on the Castle Creations Talon 90 ESC by connecting it to a Windows PC using a Castle Link USB adapter (sold separately) and opening the free Castle Link GUI software.
What is the BEC rating on the Castle Creations Talon 90 ESC?
The Castle Creations Talon 90 ESC features a heavy-duty BEC capable of delivering up to 20 amps peak power and 9 amps continuous power, ensuring steady power for high-demand servos.
Can I use the Castle Creations Talon 90 ESC in fixed-wing RC airplanes?
Yes, the Castle Creations Talon 90 ESC is perfect for aerobatic RC airplanes weighing up to 10 pounds and scale aircraft weighing up to 20 pounds.
