Triple7 V2 Servo
$157.77
Skip to product information
Only 1 Left!
Triple7 V2 Servo
$157.77
Direct 14V Power
Bypasses receiver internal BEC
Monster Torque
Up to 777 oz-in output
High Speed Performance
Blazing 0.08 second transit
Submarine Waterproof
7 point sealed protection design
Fully Programmable
Custom REEFS software parameters
Metal Gear Train
Durable 25T spline setup
In Stock
Unmatched High-Voltage SteeringPrecision power for extreme RC builds
Engineered for extreme performance, the REEFS RC Triple7 14V Servo delivers staggering steering control directly from your battery pack without stressing your ESC's internal BEC. Built inside a full CNC-machined case with submarine waterproofing, this high-powered RC car servo is the ultimate upgrade for heavy-duty RC crawler builds and demanding off-road rigs.
Customizable Power & PerformanceAdvanced programming meets raw force
Take total control over your steering setup with the REEFS RC Triple7 14V Servo, featuring parameter tuning via REEFS Software and the optional REEFS USB Link. Capable of handling direct input voltages from 10V to 14V, this brushless direct power servo generates up to 777 oz-in of torque and dynamic transit speeds as fast as 0.08 seconds. Equipped with a contact-less magnetic angle sensor, pulse width modulation control, and robust metal gears supported by three ball bearings, the REEFS RC Triple7 Servo guarantees precise response and long-lasting durability in wet and rugged environments.
Technical SpecificationsEngineered dimensions and operational metrics
Part Type
Servo
Compatible Vehicles
Universal 1/10 & 1/8 Scale RC Vehicles
Input Voltage
10V - 14V
Maximum Servo Torque
666 oz-in @ 11.1V / 700 oz-in @ 12.0V / 777 oz-in @ 14V
Maximum Servo Speed
0.10sec @ 11.1V / 0.09sec @ 12.0V / 0.08sec @ 14V
Gear Type
Metal
Spline Count
25-Tooth
Bearing
3 Ball Bearings
Deadband
2 uSec
Product Length
1.57 in (40 mm) (ruler)
Product Width
0.78 in (20 mm) (ruler)
Product Height
1.63 in (41 mm) (ruler)
Product Weight
3.12 oz
Key Performance FeaturesAdvanced engineering built for extreme conditions
Submarine Waterproofing7-point sealed protection against mud and water
Magnetic Angle SensorContact-less positioning for accurate control
Pulse Width ModulationHighly responsive PWM control logic
Fully ProgrammableCustom parameter adjustments via REEFS Software
Direct Voltage InputConnects directly to 10V-14V battery sources
Precision CNC CaseFull aluminum housing for efficient heat dissipation
Metal Gear TrainSupported by 3 ball bearings for maximum power output
Frequently Asked QuestionsEverything you need to know
Is the REEFS RC Triple7 14V Servo fully waterproof?
Yes, the REEFS RC Triple7 14V Servo features submarine-level waterproofing with 7-point seals, protecting internal components during wet and muddy driving conditions.
What is required to program the REEFS RC Triple7 14V Servo?
To program parameters such as power output, angle, and sensitivity on the REEFS RC Triple7 14V Servo, you will need the optional REEFS USB Link and REEFS Software.
Does the REEFS RC Triple7 14V Servo run directly off a LiPo battery?
Yes, the REEFS RC Triple7 14V Servo accepts input voltages from 10V to 14V using a LiPo-to-servo connector, bypassing your ESC's BEC to deliver maximum power.
