Castle Creations 40 Amp Phoenix Edge HV ESC (010-0107-00)
$129.99
Skip to product information
Low StockIn Stock
Castle Creations 40 Amp Phoenix Edge HV ESC (010-0107-00)
$129.99
In Stock
Arrives
This item ships free.
Pick up today in Cumming, usually ready in 2 hours.
Auxiliary Advantage
Multifunction Programmable Auxiliary Wire
High Voltage
Supports Up To 12S LiPo
Data Logging
Comprehensive Performance Flight Data
40A Continuous
Reliable Power Output Rating
Castle Link
Free USB Adapter Coupon Included
Arming Lockout
Enhanced Safety Lock Capability
Next Generation ControlUnmatched Versatility for RC Aircraft
The Castle Creations Phoenix Edge 40 ESC represents the next evolution in speed controller technology for RC airplanes and helicopters. Featuring an innovative programmable auxiliary wire and advanced data logging, this brushless ESC delivers unparalleled precision, versatility, and safety for serious radio control pilots.
Advanced Flight TechnologyPrecision Engineering and Customization
Take total command of your electric aircraft with the Castle Creations Phoenix Edge 40 ESC. Designed for demanding pilots, the Edge series introduces a versatile auxiliary wire that can be configured for helicopter governor gain adjustments mid-flight, audible location beacons after unexpected landings, RPM output for 3-axis gyros, or receiver arming lockouts. Built to handle up to 12S LiPo power at a continuous 40-amp draw, this high-performance speed controller features industry-leading onboard data logging to record critical power system metrics. With the included free Castle Link USB adapter coupon, fine-tuning your settings via Windows PC is simple and fully customizable.
Technical SpecificationsDetailed Electronic and Physical Dimensions
Input Voltage
3S LiPo to 12S LiPo
Max Continuous Current
40 Amps
Programmability
Castle Link USB & Field Link Card
Width
1.7 in / 43.4 mm
Length
1.8 in / 46.3 mm
Height
0.8 in / 21.4 mm
Weight With Wires
2.4 oz / 67.2 g
Weight Without Wires
1.1 oz / 30.6 g
Connectors
Sold Separately
Tools Needed
Soldering Iron and Solder
Compatible Aircraft
450 to 800 Helis & 1.20+ Fixed Wing
Part Type
Electronic Speed Controller (ESC) (settings)
Key Controller CapabilitiesInnovative Features for Peak Performance
User-Programmable Aux WireMid-flight gain adjustments, RPM output, or arming lockout
Integrated Data LoggingTracks power system performance and flight metrics
High Voltage CapacitySafe operation from 3S up to 12S LiPo setups
Castle Link SupportFree USB adapter coupon included in package
Audible Location BeaconEmits audible cue after unexpected landings
Arming Lockout SecurityEnsures system remains safely disarmed until ready
Frequently Asked QuestionsEverything you need to know
What input battery voltage does the Castle Creations Phoenix Edge 40 ESC support?
The Castle Creations Phoenix Edge 40 ESC supports input voltages from a minimum of 3S LiPo up to a maximum of 12S LiPo batteries.
What is the function of the white auxiliary wire on the Castle Creations Phoenix Edge 40 ESC?
The white auxiliary wire on the Castle Creations Phoenix Edge 40 ESC can be programmed for governor gain adjustment, an audible beacon, RPM output for 3-axis gyros, or ESC/receiver arming lockouts.
Is the Castle Creations Phoenix Edge 40 ESC fully programmable?
Yes, the Castle Creations Phoenix Edge 40 ESC is fully programmable using Castle Link software on a Windows PC, and a coupon for a free Castle Link USB adapter is included in the package.
What types of RC models are suitable for the Castle Creations Phoenix Edge 40 ESC?
The Castle Creations Phoenix Edge 40 ESC is designed for 450 to 800 size RC helicopters and 1.20 size or larger fixed-wing RC aircraft that stay within the 40-amp continuous current limit.
