AD380 Battery Discharger and Analyzer
$164.99
Skip to product information
AD380 Battery Discharger and Analyzer
$164.99
40A Discharge
Rapid High Current Discharge
380W Power
Massive Discharge Output Rating
6S Support
Handles Large Capacity Packs
Bluetooth Control
Connect Mobile App Wirelessly
3 Modes
Analyze and Discharge Safely
PC Connectivity
Graph and Track Curves
Master Battery HealthHigh Power Discharging and Diagnostics
Take complete control of your RC power sources with the Hitec AD380 DC Battery Discharger and Analyzer. Designed for competitive racers and hobbyists alike, this high-performance unit discharges high-capacity LiPo battery packs up to 6S at up to 40 amps and 380 watts. Safely return your packs to storage voltage in record time while monitoring cell performance.
Advanced Power DiagnosticsMaximize Lifespan and Power Output
The Hitec AD380 DC Battery Discharger and Analyzer is an indispensable tool for maintaining the health and power output of your RC battery collection. Featuring three versatile discharge modes, this device allows aerobatic pilots, bashers, and surface racers to analyze cell internal resistance, measure real-time capacity, and test DC-stabilized power supplies. With integrated Bluetooth technology, you can pair the discharger with the Link Power X app on iOS and Android or connect directly to a PC to visualize and compare discharge curves for peak track performance.
Technical Performance SpecificationsKey Electrical and Operational Data
Application
Battery Discharge and Analysis
Input Voltage
DC 3.0V–30.0V
Maximum Continuous Discharge Current
0.3A–40.0A
Maximum Discharge Power
380W
Display
Integrated Screen Display
Supported Battery Types
Up to 6S LiPo
Connectivity
Bluetooth / PC Link
Part Type
Battery Discharger & Analyzer
High Performance CapabilitiesEngineered for Precision Battery Diagnostics
Real-Time MonitoringDisplays real-time voltage, discharged capacity, and current
Capacity TestingBenchmarks battery packs to help select top performers
Fast Storage DischargeBrings large LiPo packs to storage level quickly
App IntegrationSupports Link Power X app on Android and iOS via Bluetooth
Power Supply Quality CheckDetects stability and quality of DC power sources
PC Graphing SupportConnect to PC to plot and compare discharge curves
Frequently Asked QuestionsEverything you need to know
What is the maximum discharge rate of the Hitec AD380 DC Battery Discharger and Analyzer?
The Hitec AD380 DC Battery Discharger and Analyzer supports continuous discharge currents up to 40.0 amps and a maximum discharge power rating of 380 watts.
Can I monitor the Hitec AD380 DC Battery Discharger and Analyzer using my smartphone?
Yes, the Hitec AD380 DC Battery Discharger and Analyzer features built-in Bluetooth technology and connects seamlessly to the Link Power X app on iOS and Android devices.
What battery cell counts are supported by the Hitec AD380 DC Battery Discharger and Analyzer?
The Hitec AD380 DC Battery Discharger and Analyzer operates across an input voltage range of DC 3.0V to 30.0V, allowing it to discharge and analyze RC battery packs up to 6S LiPo.
