HS-785HB Giant Scale Analog Karbonite Gear Sail Winch Servo
Overview:
The HS-785HB sail winch servo with it's large drum wheel has 3 1/2 revolutions of travel for hauling in even the largest of sails. With its dual ball bearing supported output shaft the HS-785HB will provide years of reliable service.
Features:
• Dual Ball Bearing Supported Output Shaft
• Large Drum Wheel
• Perfect replacement winch servo for the Pro Boat Ragazza
• *** Warning: Do not use thread lockers on Karbonite geared servo as it will cause the output shaft to fail
| Bearing: | Dual |
| Bushing Or Bearing: | Bearing |
| Current Draw Idle: | 8mA |
| Current Draw Stall: | 1500mA @ 4.8V; 1800mA @ 6.0V |
| Deadband: | 5 microsecond |
| Gear Type: | Karbonite |
| Motor Type: | 3 Pole |
| Servo Operating Voltage: | 4.8 - 6.0V |
| Servo Size Category: | Standard Large and Giant Scale |
| Servo Type: | Analog |
| Speed: | 1.68 sec/60 deg @ 4.8V; 1.38 sec/60 deg @ 6V at no load |
| Torque: | 153 oz-in (11.0kg-cm) @ 4.8V; 183 oz-in (13.2kg-cm) @ 6V |
