S63 Micro 6-port DC/USB 1S LiPo Smart Charger
$34.99
Skip to product information
S63 Micro 6-port DC/USB 1S LiPo Smart Charger
$34.99
6 Output Ports
Charge Six Batteries Simultaneously
Dual Charge Rates
Dedicated Ports for Capacity
USB & DC Power
Flexible Power Options Anywhere
LED Screen
Instant Battery Voltage Reading
Ultra Portable
Lightweight Compact Pocket Design
1S LiPo Ready
Supports Micro RC Aircraft
Power Your Micro FleetSimultaneous Multi Port Charging Solution
Keep your ultra-micro RC aircraft fleet ready for continuous flight with the Spektrum S63 Micro 6-port DC/USB 1S LiPo Smart Charger. Designed for maximum portability and field convenience, this specialized 1S LiPo charger features six completely independent ports to power multiple micro batteries at once. A digital LED display provides instant voltage feedback so you can easily manage your batteries before heading back into the air.
Effortless Micro Battery ManagementStay Airborne Longer With Spektrum
The Spektrum S63 Micro 6-port DC/USB 1S LiPo Smart Charger is an essential companion for any ultra-micro RC pilot. Equipped with six independent output charging channels, this compact device charges up to six 1S LiPo battery packs simultaneously using standard USB power or a DC power source. Ports 1 through 4 provide a 350mA current ideal for batteries up to 350mAh, while ports 5 and 6 offer a higher 500mA rate tailored for larger micro battery packs up to 750mAh. Featuring a built-in voltage checker and intuitive status LED lights, keeping your micro RC planes and helicopters powered has never been faster or easier.
Technical SpecificationsKey Metrics and Dimensions Details
Part Type
Electronics
Power Source
DC, USB
Input Voltage
5 VDC via USB charge port
Number of Output Ports
6
Maximum Charge Rate
Less than 2 Amps
Output Connector
PH 1.25
Display
LED
Battery Type
1S LiPo
Product Length
3.0 in (76 mm) (ruler)
Product Width
2.5 in (63 mm) (ruler)
Product Height
0.9 in (23 mm) (ruler)
Product Weight
1.9 oz (54 g) (scale)
Power Output
Less than 20W
Software Updates
No
Programmable
No
Advanced Charging CapabilitiesEngineered for Ultra Micro Performance
Multi-Port SystemSix independent charge output ports usable simultaneously
Dual Charge RatesPorts 1-4 deliver 350mA, Ports 5-6 deliver 500mA
Power VersatilityPowered conveniently via standard USB or DC power supply
Digital DisplayBright LED screen displays individual port and voltage information
Visual StatusSix red and green LED lights indicate charging and full status
Voltage CheckerIntegrated convenient voltage-check function for quickly auditing packs
Micro CompatibilityWorks with a variety of 1S micro battery connector types
Compact Form FactorLightweight 1.9 oz design easily fits into pocket or field bag
Frequently Asked QuestionsEverything you need to know
How do I power the Spektrum S63 Micro 6-port DC/USB 1S LiPo Smart Charger?
The Spektrum S63 Micro 6-port DC/USB 1S LiPo Smart Charger operates using a standard 5V USB charge port or a compatible DC power source, making it extremely convenient for both home charging and field use.
What battery types are compatible with the Spektrum S63 Micro 6-port DC/USB 1S LiPo Smart Charger?
The Spektrum S63 Charger is specifically designed for single-cell 1S LiPo batteries equipped with ultra-micro connectors like PH 1.25, commonly used in micro RC aircraft.
How do the individual charge ports function on the Spektrum S63 Micro 6-port DC/USB 1S LiPo Smart Charger?
Ports 1 through 4 output a 350mA current ideal for batteries rated at 350mAh or less, while ports 5 and 6 provide a 500mA output for larger micro batteries up to 750mAh.
Can I check battery voltage without charging on the Spektrum S63 Micro 1S LiPo Charger?
Yes, simply plugging a 1S LiPo battery into any port on the Spektrum S63 Charger instantly displays its current voltage on the digital LED status screen.
